Air Compressor Parts

32304610 Valve Gasket (Head Rebuild) Kit

Availability: In stock

$46.88
OR

Quick Overview

32304610 Valve Gasket (Head Rebuild) Kit - Ingersoll Rand Type-30 Replacement Compressor Parts

32304610 Valve Gasket Kit 2340

Double click on above image to view full picture

Zoom Out
Zoom In

More Views

  • 32304610 Valve Gasket Kit 2340

Details

32304610 Valve Gasket (Head Rebuild) Kit - Ingersoll Rand Type-30 Replacement Compressor Parts Valve Gasket Kit for Model 2475 - It includes parts needed to rebuild High Pressure (HP) and Low Pressure (LP) Valve Plates. Also gaskets to rebuild compressor

Includes following Parts:

Air Head Gasket HP 32247926
Air Head Gasket LP 32247934
VP-HP Cylinder O-Ring 32246878
VP-HP Cylinder Gasket 32246910
HP Inlet Finger Valve 32236671
Retainer Finger Valve 32297343
Hex Head Cap Screw 32247512
Nut M4 Hex 32248171
HP Disch. Valve Retainer 97511000
HP Disch. Finger Valve 32241010
HP Disch. Damper Valve 32294472
LP Inlet Finger Valve 32241002
Hex Head Cap Screw 32297327
Hex Nut 97511059
LP Disch. Finger Valve 32241036
LP Disch. Valve Retainer 97511091
